Mean Well RSP-75-15 DIY

Description

• Closed design with fan
• Universal input
• Short circuit, overload, surge protection
• Screw terminals
• Input voltage: 90 - 264 V

MEAN WELL RSP-75-15 Total power: 75 W, AC input voltage: 85 - 264 V, AC input frequency: 47 - 63 Hz. Power supply unit (PSU) form factor: 1U, Mean time between failures (MTBF): 296700 h. Product colour: Metallic. Width: 97 mm, Depth: 159 mm, Height: 30 mm. Rise Time: 30ms Weight and dimensions:

- Width: 97 mm.
- Depth: 159 mm.
- Height: 30 mm.
- Weight: 440 g.

Performance

- Total power: 75 W.
- AC input voltage: 85 - 264 V.
- AC input frequency: 47 - 63 Hz.
-Power Factor Correction Filter (PFC): Active
- Holding time: 16 ms.
- Efficiency: 86%.
-Power protection features: Over voltage, overload, short circuit

Operating conditions

- Operating temperature: -25 - 70 C.
- Storage temperature range: -40 - 85 C.
- Operating relative humidity: 20 - 90%.

Other functions

- Rise time: 30 ms.

Design

-Product colour: Metallic
- LED indicators: yes.

Benefits

- Power supply unit (PSU) form factor: 1U
- Average operating time between failures (MTBF): 296700 h
