S.M.S.L RAW PRO-DAC1 DAC Digital to Analog Convertor ES9039MSPRO XU316 MQA-CD PCM 32bit 768kHz DSD512 LDAC with Remote Control

Description

• ES9039MSPROThe Newly American ESS DAC Chip,Flagship ES9039MSPRO.USB, Optical, and Coaxial support MQA Decoding,and support MQA-CD.
• XMOS XU-316A true 32-bit UsB scheme supports DOP and native DSD PCM supports up to 768kHz and DSD up to DSD512.
• Low Phase Noise Crystal Oscillator and Clock Processing CircuitLow phase noise crystal oscillator and optimized clock processing circuit are used to achieve low clock jitter.
• Compatible with Various Input FormatsAll interfaces except Bluetooth support DSD transmission.Coaxial, optical fiber and AES/EBU are compatible with DOP64 format.
• Low Noise Power Supply ProcessingSpecially designed power supply system and multiple low-noise regulated power supplies provide low-noise power supply for analog circuits.

Specification
Input:USB/Optisch/Koaial/Bluetooth/FS/AES/EBU
Output:RCA/XLR
Output Amplitude:XLR/5.2VrmsRCA/2.5Vrms
Output impedance:XLR/100RCA/100
THD+N:XLR/0.00005%(-125dB)(UN-WTD)RCA/0.00007%(-123dB)(UN-WTD)
Dynamic range:XLR/132d8RCA/127dB
SNR:XLR/132dBRCA/127dB
USB transmission: USB2.0 (Asynchronization)
USB compatibility: Windows7/8/8.1/10 /11(Needs Driver)Mac OSX10.6 above, Linux(Driverless)
MQA Decoder:USB/Optical/Coaxial/AES/EBU
MQA-CD Decoder:Optical/Coaxial/AES/EBU
Sampling rate & Bit Width:
USB / I2S:PCM 44.1~768kHz(32bit)DSD 2.8224~22.5792MHz(1bit)
Optical/Coaxial/AES/EBU:PCM 44.1~192kHz(24bit)DoP DoP256(USB),DoP64(Optical/Coaxial)
Bluetooth specifcation5.1(support SBC,AAC,aptx,aptX HD,LDAG)
Power Consumption<20W
Standby power<0.5W
Size: 254X203X48mm (WxHxD)
Weight1.9kg/4.19lbs
