XFCZMG FRDM-K64F Embedded System Development Boards and Kits

Description

• Type:MCU 32-Bit
• Core Processor :ARM Cortex-M4
• Utilized IC / Part :K24, K63, K64, mbed-Enabled Development
• Interconnect System :Arduino R3 Shield
• Suggested Programming Environment :Mbed-Enabled

Product Technical Specifications

Dev Kit Description
The FRDM-K64F is an ultra-low-cost development platform for K64, K63, and K24 MCUs. The FRDM-K64F hardware is form-factor compatible with the Arduino R3 pin layout, providing a broad range of expansion board options. The FRDM-K64F is feature packed with a lot of peripherals to enable rapid prototyping, including a 3-axis digital accelerometer and magnetometer to create full e-Compass capabilities, a tri-colored LED and 2 user push-buttons for direct interaction and feedback, expansion memory with a microSD card slot, and connectivity options using onboard Ethernet port and headers for use with Bluetooth and 2.4 GHz radio add-on modules. The FRDM-K64F platform features OpenSDAv2, the Freescale open source hardware embedded serial and debug adapter running an open source bootloader. This circuit offers several options for serial communication, flash programming, and run-control debugging.

Dev Kit Features
MK64FN1M0VLL12 MCU (120 MHz, 1 MB flash memory, 256 KB RAM, low-power, crystal-less USB, and 100 Low profile Quad Flat Package (LQFP))
Dual role USB interface with micro-B USB connector
RGB LED
FXOS8700CQ accelerometer and magnetometer
Two user push buttons
Flexible power supply option OpenSDAv2 USB, K64 USB, and external source
Easy access to MCU input/output through Arduino R3 compatible I/O connectors
Programmable OpenSDAv2 debug circuit supporting the CMSIS-DAP Interface software that provides: Mass storage device (MSD) flash programming interface
CMSIS-DAP debug interface over a driver-less USB HID connection providing run-control debugging and compatibility with IDE tools
Virtual serial port interface
Open source CMSIS-DAP software project

Ethernet
SDHC
Add-on RF module: nRF24L01+ Nor
